ET205SY
Order No.:
Stock:
Delivery Time:
Without Tax: $
Machine video: https://www.youtube.com/@Chinamachinetool
Key Features:
|
Item |
Specification |
Unit |
ET-205SM |
ET-205SY |
|
Capacity |
Max. swing dia. over bed |
mm |
Φ550 |
|
|
Max. swing dia. over slide |
mm |
Φ290 |
Φ200 |
|
|
Max. turning length |
mm |
400 |
||
|
Max. turning dia. |
mm |
Φ380 |
Φ300 |
|
|
Spindle |
Spindle transmission type |
/ |
Mechanical spindle, belt-drive |
|
|
Spindle bore |
mm |
Φ66 |
||
|
Spindle end type |
/ |
A2-6 |
||
|
Spindle speed |
rpm |
4500 |
||
|
Spindle max. bar through dia. |
mm |
Φ51 |
||
|
Spindle motor power |
kw |
11 |
||
|
Spindle chuck size |
‘’ |
8’’ |
||
|
Spindle C axes division accuracy |
Deg |
0.001° |
0.001° |
|
|
Sub-spindle |
Sub-spindle transmission type |
/ |
Electro-spindle, direct-drive |
|
|
Sub-spindle bore |
mm |
Φ56 |
||
|
Sub-spindle end type |
/ |
A2-5 |
||
|
Sub-spindle rated/max. speed |
rpm |
1750/6000 |
||
|
Sub-spindle max. bar through dia. |
mm |
Φ44 |
||
|
Sub-spindle motor power |
kw |
11 |
||
|
Sub-spindle chuck size |
‘’ |
6’’ |
||
|
Sub-spindle rapid moving speed |
m/min |
28 |
||
|
Sub-spindle travel |
mm |
490 |
||
|
X/Y/Z axes |
X/Y/Z axes linear guideway type |
/ |
Roller |
|
|
X axes travel |
mm |
170+20 |
||
|
Y axes travel |
mm |
/ |
±40 |
|
|
Z axes travel |
mm |
550 |
||
|
X/Z axes rapid moving speed |
m/min |
30 |
||
|
Y axes rapid moving speed |
m/min |
/ |
30 |
|
|
Tool turret |
Tool turret type |
/ |
BMT55 Power tool turret |
BMT55 Powered tool turret |
|
Tool qty |
/ |
12T |
||
|
Vicinal tool changing time |
s |
0.28 |
||
|
Farthest tool changing time |
s |
0.4 |
||
|
Toolshank size |
mm |
|||
|
Live tool motor power |
kw |
4.5 |
4.5 |
|
|
Live tool motor torque |
Nm |
15 |
15 |
|
|
Live tool max. speed |
rpm |
4000 |
4000 |
|
|
Accuracy |
Ex-circle finish turning accuracy |
/ |
IT6 |
|
|
Finish turning roughness |
mm |
Ra0.4~1.6 |
||
|
Finish turning roundness |
mm |
≤0.003 |
||
|
Positioning accuracy(X/Z) |
mm |
0.005/0.008 |
||
|
Repeat positioning accuracy(X/Z) |
mm |
0.002/0.004 |
||
|
Others |
Coolant pump motor |
w |
480 |
|
|
N.W. |
kg |
4450 |
||
|
Overall size |
mm |
2605/3630×1720×1840/(exclude/include chip conveyor) |
||
