VMC850
Order No.:
Stock:
Delivery Time:
Without Tax: $
Machine video: https://www.youtube.com/@Chinamachinetool
Key Features:
|
Model |
Unit |
VMC850 |
VMC855 |
VMC1160 |
||
|
Table |
Table size |
mm |
1000*500 |
1000*550 |
1100*500 |
|
|
T-slots |
mm |
18*5*100 |
18*5*100 |
18*5*100 |
||
|
Max. loading |
kg |
750 |
750 |
750 |
||
|
Stoke |
X Axis travel |
mm |
850 |
850 |
1000 |
|
|
Y Axis travel |
mm |
500 |
550 |
600 |
||
|
Z Axis travel |
mm |
550 |
600 |
580 |
||
|
Spindle |
Spindle nose to table |
mm |
120-720 |
120-720 |
270-850 |
|
|
Spindle center to table |
mm |
540 |
612 |
575 |
||
|
Spindle speed |
rpm |
12,000 |
12,000 |
10,000 |
||
|
Spindle taper |
Type |
BT-40 |
BT-40 |
BT-40 |
||
|
Feeding |
Quick move |
X，Y Axis |
m/min |
36.36 |
36.36 |
36.36 |
|
Z Axis |
m/min |
30 |
30 |
30 |
||
|
Cutting feed |
mm/min |
1-10000 |
1-10000 |
1-10000 |
||
|
Min. input |
mm |
0.001 |
0.001 |
0.001 |
||
|
Tool Magazine |
Max. Diameter of tol |
mm |
φ80（φ130） |
φ80（φ130） |
φ80（φ130） |
|
|
Max. length |
mm |
350 |
350 |
350 |
||
|
Max. weight |
kg |
8 |
8 |
8 |
||
|
Opt |
|
|
|
|
||
|
Tool shaft |
Type |
BT-40 |
BT-40 |
BT-40 |
||
|
Tool quantity |
Pieces |
24 |
24 |
24 |
||
|
Tool change model |
- |
Arm |
Arm |
Arm |
||
|
Tool change time |
Sec |
3 |
3 |
3 |
||
|
Motor |
Control system |
|
Oi--MD |
Oi--MD |
FANUC 0i-MD |
|
|
Spindle motor |
kw |
7.5/11 |
7.5/11 |
11/15 |
||
|
Sevo motor (X/Y/Z) |
kw |
1.8/1.8/3.0 |
1.8/1.8/3.0 |
1.8/1.8/1.8 |
||
|
Spindle oil cooling |
W |
750 |
750 |
750 |
||
|
Auto lubrication |
w |
30 |
30 |
30 |
||
|
Colant pump |
w |
840 |
840 |
840 |
||
|
Electric |
KVA |
25 |
25 |
25 |
||
|
Others |
Air |
kg/cm |
6 |
6 |
6 |
|
|
Water tank |
L |
300 |
300 |
300 |
||
|
positioning accuracy |
mm |
0.008 |
0.008 |
0.008 |
||
|
Repeat ablity |
mm |
0.004 |
0.004 |
0.004 |
||
|
Net weight |
kg |
5000 |
5000 |
5700 |
||
|
Gross weight |
kg |
5500 |
5500 |
6000 |
||
|
Machine size |
mm |
4100*2970*3000 |
4100*2970*3000 |
4100*2970*3000 |
||
