Horizontal five-axis

Description

THM6363IV

THM6380IV

THM63100IV

THM63125IV

Unit

Pallet

Pallet dimension（diameter）

630

800

1000

1200

mm

A-axis indexing

0.0001°×900000

0.001°×110000

0.0001°×900000

0.001°×90000

°

B-axis indexing

0.0001°×3600000

0.001°×360000

0.0001°×3600000

0.001°×360000

°

Max. B-axis rpm

15

10

10

10

r/min

Loading capacity

0～45°

500

1000

1000

1000

Kg

45～90°

300

800

800

800

Kg

Max. Workpiece swing diameter

0~70°

700

900

1100

1200

mm

70~90°

630

Travel

X  (Column)

1000

1300

1300

1300

mm

Y （headstock）

800

1000(Opt:1200)

1000 (Opt: 1200)

1200

mm

Z （worktable）

900

1100

1100

1100

mm

Spindle nose to table surface

-200~600

-200~800(Opt:1000)

-200~800

-320~880

mm

Spindle nose to table center

150~1050

200~1300

200~1300

200~1300

mm

Spindle

Spindle taper

No.50

No.50

No.50

No.50

Spindle rpm

20～6000

20～5000

20～5000

20～5000

r/min

Speed selection

Programmable In full range

Spindle motor

17/22.5

31

28/34.5

31

Kw

Max. spindle torque

277

302

477

302

N.m

Tool magazine

Tool capacity

40

40

40

40

pcs

Tool type

BT50

BT50

BT50

BT50

Pin type

ISO7388/2-A

ISO7388/2-A

ISO7388/2-A

ISO7388/2-A

Max. Tool diameter allowed

φ125（full loaded ）

φ120（full loaded ）

φ120（full loaded ）

φ120（full loaded ）

mm

φ250（interval loaded）

φ245（interval loaded）

φ250（interval loaded）

φ245（interval loaded）

mm

Max. Tool length

450

500

500

500

mm

Max. tool weight

20

25

25

25

Kg

Tool change time （tool to tool）

3.5

9

4.5

9

s

Tool selection

Bi- direction

Fixed

Fixed

Fixed

Axis driven

Federate

0～20

0～20

0～20

0～20

m/min

Rapid feed

45

45

40

40

m/min

Location feedback（X、Y、Z、A、B）

Optical scale

Optical scale

Optical scale

Optical scale

Positioning accuracy (GB/T 20957.4-2007)

Linear axis positioning accuracy

0.008

0.008

0.008

0.008

mm

Linear axis repeatability

0.004

0.004

0.004

0.004

mm

A-axis positioning accuracy

15

15

15

15

″

A-axis repeatability

7

7

7

7

″

B-axis positioning accuracy

8

8

8

8

″

B-axis repeatability

4

4

4

4

″

Machine accuracy (GB/T20957.1-2007)

Installation data

Machine weight

16

22

26

30

t

Nominal Power consumption

60

100

100

100

KVA

Power supply

380V/50Hz/3 phase

380V/50Hz/3 phase

380V/50Hz/3 phase

380V/50Hz/3 phase

Air pressure

0.6

0.6

0.6

0.6

MPa

Air flowrate

280

380

380

380

L/min

Electric

SINUMERIK  840D

Input/output resolution 0.001mm

Working zone protection

SIMODRIVE 611 digit servo driven

Tool radius compensation

Profile detecting

5-axis simultaneous control

Tool length compensation

Spindle monitoring

10.4″TFT display.  Menu operation, soft key function

Ball screw pitch compensation

Location monitoring

Linear interpolation/circular interpolation/ helix interpolation

Spindle rpm direct programming. Spindle rpm magnification 50~120%

Hard disc storage=40GB（10GB for customer data storage）

Tapping/threading

Reverse black-lash compensation

Soft limit

Constant linear speed cutting

AUTOMATIC

Spindle stop

Workpiece coordinate system selection

JOG

RS232C interface

G-code programming. /ASCⅡ code programming

TEACH IN

Rigid tapping

Advanced language programming

MDI

Coordinate system setting ≥6 nos

Metric/inch system programming

REPOS

Mirror Image function

Absolute or incremental programming

Dry run（program inspection）

Plane selection

Functional programming

SINGLE BLOCK

Coordinate system rotation, zooming

Profile programming

OPTIONAL STOP

Program management

R-parameter variant programming (Customer Micro programming )

Safety monitoring. (Circuit, over-heat, cell, voltage, storage, limit switch, fan, EPROM

PLC: SIMATIC S7    CPU  S7    I/O module

Polar system programming

PROGRAM SKIP

STEP7 PLC programming

Sub-program

MANUAL HOMING /RETURN TO REFERENCE POINT

Program simulation display.

Background edit

FIXED CYCLE (Drilling, milling, boring, tapping and etc

Manual operation unit.

Feed override 0～120%

PROGRAM SKIP

Program setting
