VMC400
Order No.:
Stock:
Delivery Time:
Without Tax: $
Machine video: https://www.youtube.com/@Chinamachinetool
Key Features:
| Specification | VMC400/500 |
| Table dimension | 800x450 мм/1000x500MM |
| Max table load | 400 KG/500KGr |
| T-slot | 3*18*90 |
| Max tool diameter (Adjacent without tool) | 80MM/130 MM |
| Distance from spindle nose to table | 120 - 620 мм/105 - 655MM |
| Travel of X/Y/Z | 600/500/500 |
| Raoid traverse rate of X/Y/Z | 36/36/30 |
| Distance from spindle center line to column guide | 550 /595MM |
| Spindle speed | 8000 r/min |
| Type of tool shank/rivet | BT 40 |
| Tool storage capacity | 24 Disc type. |
| Tool changing time | 2.0 (tool to tool) |
| Positioning accuracy | ± 0.005 mm / 300 |
| Repeated positioning accuracy | ± 0.003 mm |
| Spindle motor power(a motor torque106N.m) | 5.5/7.5 кw/ 7.5/11кw |
| Overall dimensions | 2.4x2.14x2.8 м/2.7x2.1x2.9 M |
| Net weight | 4200 кг/5500кг |
