VMC540H
Order No.:
Stock:
Delivery Time:
Without Tax: $
Machine video: https://www.youtube.com/@Chinamachinetool
Key Features:
| Specification | VMC540H |
| Table dimension | 1200x540MM |
| Max table load | 800KG |
| T-slot | 18*4*125 |
| Max tool diameter (Adjacent without tool) | 80MM/130 MM |
| Distance from spindle nose to table | 550 - 1060 MM |
| Travel of X/Y/Z | 1020/560/510 |
| Raoid traverse rate of X/Y/Z | 36/36/30 |
| Distance from spindle center line to column guide | 587 MM |
| Spindle speed | 8000 r/min |
| Type of tool shank/rivet | 7月24日 |
| Tool storage capacity | 24 Disc type. |
| Tool changing time | 1.5(tool to tool) |
| Positioning accuracy | ± 0.004 mm / 300 |
| Repeated positioning accuracy | ± 0.002 mm |
| Spindle motor power(a motor torque106N.m) | 11/15кw |
| Overall dimensions | 2.96x2.45x3.1M |
| Net weight | 6500кг |
