GMC13/GMC15/GMC18/GMC22/GMC27
Order No.:
Stock:
Delivery Time:
Without Tax: $
Machine video: https://www.youtube.com/@Chinamachinetool
Key Features:
Machine tool features GMC series CNC gantry machining center has multiple processing functions such as milling, boring, drilling, reaming, countersinking, tapping, etc. The product's technical indicators and configuration are leading in China, the product structure and process are mature, the quality is stable, the torque is large, and it is suitable for the needs of various mechanical processing fields such as automobiles, molds, aerospace, packaging, hardware, etc. ① The machine tool adopts high-quality castings, the gate bridge and the base are integrally formed, and the structure is analyzed by finite elements to provide the best stability and precision. ② X, Y, and Z axes all use imported precision-grade large-diameter screws with pre-stretching design. ③ The linear guide rails use precision-grade heavy-duty imported guide rails to ensure high-precision and high-load processing requirements. ④ The Z axis adopts a nitrogen balance system. ⑤ The water tank is equipped with an oil-water separation device to recycle the guide rail oil, protect the environment, and extend the service life of the cutting fluid.
